Geomarine Tidal Expert
is the cost-effective way to accurately record water levels, with the added option to perform constituent analysis using radar and pressure sensors.
Elevate Your Tidal Measurements
Where Innovation Meets Accuracy
The Geomarine Tidal Expert is a cutting-edge automation tide gauge designed to measure tidal fluctuations with precision. Featuring advanced tidal analysis tools, this device ensures reliable and real-time monitoring of sea level changes. Perfect for research, monitoring, and coastal management.
Specifications
Explore the advanced features and technical specifications of the Geomarine Tidal Expert and its complementary devices.
Geomarine Tidal Expert
- Tidal Observation: Pressure Transducer Option
- Type: Vented strain gauge with stainless steel mounting bracket
- Range: Standard 10dBar (~10m), with 20m cable Other ranges and lengths available
- Pressure Accuracy: ±0.1% of full scale
- Radar Level Sensor Option: See data sheet for full details
- Minimum Range: 0.8m
- Maximum Range: 20m
- Beam Angle: ±6°
- Frequency: 25 GHz
- Radar Accuracy: ±10 mm
- Precision: 1 mm
Geomarine Tide Logger
- Logging Unit Housing & Bracket: Injection moulded housing rated to IP67
- Power: Alkaline cells provide power for up to a year of autonomous sampling
- Memory: 512 MB SD card memory (effectively unlimited data storage)
- Sampling: Custom sampling mode (Burst & Continuous Sampling Mode)
- Switching: Power switch on unit
- Resolution: Data logged to 1mm resolution
- Comms: Integral wireless module for short range wireless communication RS232/RS485 for cabled communication
- Dimensions: Housing: 52 mm x 144.5 mm x 197 mm
- Weight: ~15 kg including batteries
Geomarine Tide Analyzer
- Telemetry: Radio (see UHF telemetry data sheet for full details)
- Frequency: Selectable frequency UHF synthesized radio transceiver, (403...473MHz)
- Software: System is supplied with TideMaster Express Windows based PC software, for instrument setup, data extraction and display.
- Analysis Features: Tidal constituent analysis, vertical datum control, and remote web-based control
